Hitbox 7 In 1 Mig Welder

HITBOX Gasless/Gas MIG Weld Aluminum Welder 110V 220V Lift TIG MMA 200Amp LCD Welding Machine Why did you choose the HITBOX HIM250 DPP? Here are the reasons: 1.Silent Professional MIG Welder: The HITBOX 4-in-1 synergistic control welder is equipped with a digital LCD display that clearly shows each step of the welding process, making welding simple and efficient. You only need to set the welding mode, material, wire/electrode/tungsten size, and plate thickness. Recommended suitable adjustments for current, voltage, and welding mode, as well as wire diameter, metal type and thickness, and the 2T/4T spot welding mode. Silent - Protect your ears from noise. 2.Aluminum Anti-Stick Welder: The HITBOX HIM250 DPP 200Amp welding machine can weld aluminum, iron, carbon steel, stainless steel, and more. It is suitable for pipe installations, mold repairs, petrochemicals, architectural decorations, car repairs, bicycles, crafts, and general manufacturing. Even beginners can handle any task efficiently and easily with this machine. Note: When welding aluminum, the graphite guide sleeve must be replaced! (Included) 3.MIG/MAG Welder: With a high-quality wire feeder for smooth and stable wire feeding. Suitable for MIG/MAG/Flux-Core welding. MIX GAS/CO2 gas welding is suitable for 0.8 / 1.0 mm solid metal wires. It is ideal for welding metal plates with a thickness of 0.7 to 8 mm. FCAW-S means gasless MIG welding. It uses 0.8-1.0 mm flux wire and is suitable for welding plates with a thickness of 1-6.4 mm. The 2T/4T function prevents hand fatigue during welding. The weld bead is well-formed, the arc is more stable, there are fewer spatter, and no sticking. 4.LIFT TIG/ARC Welder: TIG welding is suitable for 1.6 mm and 2.4 mm tungsten. It can weld materials with a thickness of 1.0 to 6.4 mm. Tip: Can be used with WP-26V TIG torches. Arc welding melts 2.5 / 3.2 / 4.0 mm electrodes. It can weld plates with a thickness of 1.6-8.0 mm. Extending the power cable by 160 feet can withstand cable attenuation and allows the machine to work normally. It is very suitable for work on construction sites, home maintenance, dock facilities, and even on agricultural land. 5.2-Year Warranty and Excellent Customer Service: HITBOX offers a good warranty. We have a professional technical team. If you encounter any issues while using this machine, feel free to contact us. Product Features: HITBOX HIM250 DPP 200amp 110V/220V Aluminum MIG welding machine
* 5 in 1 welders: MIG gasless welder、MIG MIX gas welder、MIG CO2 gas welder、TIG welder（Lift）、ARC welder. * 2 ways to use: Synergy MIG-Set welding parameters: semi-automatic welding-Intelligent recommended welding parameters. * MAN-MIG：adjust parameters by yourself that professional welders like. * HD digital LCD display: Clearly show each of your welding parameters, Make welding easier. * Output current: 0-200Amp adjustable current, MMA: 170A、 TIG：200A、MIG：200A. * Weldable metal wide range: Iron, carbon steel, stainless steel, aluminum silicon（Al&Si）, aluminum magnesium（Al&Mg）, copper silicon, copper magnesium and other metals.   Product Details: - Brand:HITBOX
- Model:HIM250 DPP
- Inverter technology: IGBT
- Rated input voltage (V)-110V/220V
- Frequency (HZ)-50/60
- Rated input power (KW)-MIG: 5.7; TOG: 4.37; MMA: 6.3
- Rated input current (A)-MIG: 36.0; TIG: 28.1; MMA: 40.5
- Rated input apparent power (KVA)-MIG: 7.8; TIG: 6.21; MMA: 8.9
- Welding current adjust range (A)-10 ~ 200
- Welding voltage adjust range (V)-10 ~ 26
- Duty cycle (40℃ 10min)-25%, 200A; 60%, 150A; 100% 130A
- No load voltage (V)-50V (adjustable)
- Power factor-MIG: 0.73; TIG: 0.70; MMA: 0.71
- Efficiency(%)-≥80%
- Protection class-IP23
- Insulation class-F
- Cooling:AF
- Wire diameter(m): Fe: 0.6/0.8/1.0; Ss: 0.8/1.0; AI: 0.9/1.0; Flux: - 0.9/1.0/1.2
- Electrode Type:6013;7018;7014 etc
- Wire diameter: 0.6/0.8/1.0mm(1kg/5kg)
- Welding thickness: 1-12mm
- Electrode Diameter(mm): Ø2.5, Ø3.2,Ø4.0
- Welding materials: Iron, stainless steel, aluminum, galvanized sheet, carbon steel, copper and other metals Operating Parameters: - MIG FUNCTION：MIX GAS can use 0.6/ 0.8/ 1.0/ 1.2mm flux wire. it can weld 0.7 ~ 6.4mm thickness. 2. GAS (CO2) can use 0.8/ 1.0mm wire. Can weld 0.9 ~ 6.4mm thickness
- TIG FUNCTION：Can use 1.6mm and 2.4mm tungsten. Can weld 0.7 ~ 6.4mm thickness.
- MMA FUNCTION：Current 10 ~ 170 amp. Can weld 2.5/ 3.2 mm electrode. can weld 1.6 ~3.4mm thickness.   Package Included: 1X HITBOX double pulse HIM250 DPP mig welder
1X Mig torch
1X Earth clamp(70.86inch)
1X Electrode holder(70.86inch)
1 X 1.0mm/1.2mm U shape drive roller 1 X 0.8mm/1.0mm V shape drive roller
1X Gas tube
2X Hose clamps
1X Welding brush
1X User's manual
1X Graphite wire feed tube:when welding aluminum, please do use it with the mig gun.
1X 220V to 110V convert plug Note: This link does not include the WP-17V TIG torch. On Dec 5, 2024 at 19:16:33 PST, seller added the following information:
